This welding joint has strong advantages in welding applications of metals such as copper, aluminum, stainless steel, carbon steel, etc
It is an economical and efficient welding head.
The welding joint is driven by a high-speed pan tilt motor, and the size of the swing circle is manually adjusted
Can be equipped with various lasers with QBH connectors.
Full optics and body water cooling improve the stability and service life of welded joints
Easy to install, no need for debugging.
Stable and reliable, capable of carrying 3000W power
|
Technical parameters |
|
|
maximum power |
3000W |
|
Collimate/focus focal length |
F100 F200/250/300 |
|
Swing range |
0.1—4mm |
|
Cooling method |
water-cooling |
|
Rotation speed |
0—8000rpm |
|
weight |
2.6KG |
|
Optional selection |
Coaxial, wind knife, wire feeding mechanism, side blowing, red light bracket |
